    International Standard Refractory Brick Continuous Casting Machine for Steel Industry

    Product Description

    International Standard Refractory Brick Continuous Casting Machine for Steel Industry

    China refractory brick manufacturer continuous casting machine low price refractory ladle slide gate plate for steel industry

    Ladle slide gate system for steel ladle or tundish is made of Tabular corundum, Resin, Zirconia, Carbon, Graphite, Bauxite as the main raw materials of shaped refractory products, the main component is Al2O3.

    slide gate plate becomes more and more important in the process of modern steel smelting, becoming an indispensable part of smelting.It is in the process of continuous casting machine casting steel control device, can accurately adjust the water flow from the ladle in continuous casting tundish, the inflows and outflows of molten steel in balance, so that the continuous casting operation is easier to control.

    Slide Gate Plate is a kind of slide gate refractory that is designed to control the flow of molten steel during steel making. The performance of this refractory is dependent upon the ability to resist thermal shocks, abrasion, and corrosion. Henan Hongtai has been manufacturing and exporters of slide gate plates and supplying them to clients in steel industry across the world. The slide gate plates are in high demand among the clients because the company is able to control the factors influencing their performance.

    Materials used by Henan Hongtai to make Slide Gate plate

    Slide gate plates are made by Henan Hongtai after taking into account plant related conditions and specific operating conditions. The materials used for manufacturing slide gate plates are dependent upon grade of steel being produced, casting time, quantity of steel, and temperature of molten steel.

    Our slide gate plate retain their shape and bore diameter is not affected by flow of molten steel. Slide gate plates made by Henan Hongtai posses many features that allow them to give high and consistent performance time after time.

    Slide Gate Plates features are as follows.

    Resistance to thermal shocks
    Ability to resist corrosion caused by molten steel and slag
    Resistance to abrasion
    Low porosity and high bulk density
    Great mechanical strength
    Ability to withstand high temperatures
    Ability to resist structural changes because of high operating temperatures
    Great resistance to oxidation
    Smooth surface finish

    Specification

    China refractory brick manufacturer continuous casting machine low price refractory ladle slide gate plate for steel industry

    Slide Gate Plate technical data:

    International Standard Refractory Brick Continuous Casting Machine for Steel Industry

    IndexLadle Slide Gate Plate
    TypeAl2O3-ZrO2-CAl2O3-ZrO2-CAl2O3-ZrO2-CAl2O3-C
    HBLTG-90HBLTG-80HBLTG-75HBLS-65
    Raw materialTabular corundum, Resin, Zirconia, Carbon, GraphiteTabular corundum, Resin, Zirconia, Carbon, Graphite, BauxiteTabular corundum, Resin, Zirconia, Carbon, Graphite, BauxiteTabular corundum, Resin, Zirconia, Carbon, Graphite, Bauxite
    Al2O3% Min90807565
    C% Max6.06.06.07.0
    ZrO2% Min4.04.04.0
    A.P.% Max5678
    BD% Min3.13.02.92.8
    C.C.S.MPA Min12011511090
    HMOR Mpa (1400*30min)125120120
    Service life(heats)4-8 (ironclad)2-42-31
    Service life depends on steel-making condition and differentconditions.
    The products can be customized as per your demands
    International Standard Refractory Brick Continuous Casting Machine for Steel Industry
    Usage

    China refractory brick manufacturer continuous casting machine low price refractory ladle slide gate plate for steel industry

    International Standard Refractory Brick Continuous Casting Machine for Steel Industry

    International Standard Refractory Brick Continuous Casting Machine for Steel Industry

    Alumina-Carbon-Zircon Slide Gate Plate for Steel Ladles and tundish is a key component of a sliding nozzle, molten steel is direct control, determines a sliding nozzle member functions. The manufacturing process of the slide gate plate is different from the previous refractory materials.Flake Graphite Alumina-Carbon-Zircon Nozzle Slide Gate Plate for Steel Ladles has a molten steel injection function and a flow adjustment function.In addition to the processes of kneading, molding, firing, and inspection, there are also machining, installation and external processing of sliding surfaces. Overall adjustment process.


    During use, due to long-term chemical corrosion and physical erosion of high temperature molten steel, severe and transient thermal shock and mechanical wear, the use conditions are extremely harsh; at the same time, in order to achieve free opening and closing of steel flow, the sliding surface is flat Strict requirements are required for the degree and plate size. Therefore, the slide gate plate must have the characteristics of high strength, wear resistance, slag resistance and good thermal shock stability.

    Packaging & Shipping

    China refractory brick manufacturer continuous casting machine low price refractory ladle slide gate plate for steel industry

    International Standard Refractory Brick Continuous Casting Machine for Steel Industry


    Packaging of slide gate plate for steel ladle and tundish:

    1.International standard seaworthy exportable packing.
    2.Wooden pallet.
    3.Wooden / bamboo case (box)..
    4.Further packing information will be based on customer's requirements.

    International Standard Refractory Brick Continuous Casting Machine for Steel Industry
    Shipping details for slide gate plate for steel ladle and tundish:

    1.The sample willl be send by International expresses FEDEX/DHL/UPS/TNT.
    2.The goods are transport by shipping.

    Hot Sale Ladle Slide Gate Manufacturer with Competitive Price

    Slide gate plate Payment Item :

    1. Payment: T/T, Western Union,LC; Usually 30% deposits,70% balance before delivery or negotiations to solve.
    2. MOQ: Usually 1Tons
    3. Quality Warranty: 1 years

    Slide gate plate Delivery time :

    1.Stocks:Within 5-7 days after receive the deposit.
    2.Customization:Within 15-30 days after receive the deposite.
